24 Pin 0.50 mm Pitch ZIF FPC Connector F05057FA024M1WLJ9

Product Overview

24 Pin 0.50 mm Pitch FPC Connector featuring a ZIF structure and 2.1 mm height. F05057FA024M1WLJ9 is a 24 pin assembly designed for compact flexible circuit connections where board space and connector height are important.

Product Specifications

Product Features

• 24 Pin Configuration Provides 24 contacts for compact flexible circuit connection applications.
• 0.50 mm Pitch Supports fine pitch PCB layouts where board space is limited.
• ZIF Structure Allows flexible circuit insertion with a zero insertion force connection design.
• 2.1 mm Low Profile Helps reduce connector height in compact electronic assemblies.
• Compact FPC Interface Provides a space-efficient solution for flexible circuit connections on PCBs.

Packing Details

Standard packaging can be provided according to product quantity, handling requirements, and customer specifications.

Applications

• Consumer Electronics Compact electronic devices and control boards.
• Display Modules Flexible circuit connections for display assemblies.
• Industrial Electronics Compact control and interface equipment.
• Communication Devices Internal FPC connection applications.
• Embedded Systems Space-conscious electronic assemblies.

Frequently Asked Questions (FAQ)

Q: What are the pin count and pitch of this FPC connector?
A: F05057FA024M1WLJ9 features 24 pins with a 0.50 mm pitch, according to the product drawing.

Q: Is this 2.1 mm low profile FPC connector suitable for compact PCB assemblies?
A: Yes. The 2.1 mm height and 0.50 mm pitch provide a compact configuration for space-conscious PCB designs.

Q: What type of FPC connection does this 24 pin connector use?
A: The drawing identifies F05057FA024M1WLJ9 as a ZIF FPC connector assembly with a 0.50 mm pitch.
