QSFP28 1x1 Cage SFP Cage Connector S501120010SA4（Cross out SAMTEC QSFPC-PF-02）

Product Overview

QSFP28 1x1 Cage S501120010SA4 provides robust EMI protection and optimal thermal dissipation for high-density 100G Ethernet applications. Designed for QSFP MSA compatible transceivers, it features a stainless steel cage body and black anodized aluminum heatsink to ensure reliable signal integrity and long-term network operational stability.

Product Specifications

Product Features

• • Durable Construction: Stainless steel body cage and EMI fingers ensure high mechanical strength and corrosion resistance.
  • Enhanced Thermal Cooling: Black anodized aluminum heatsink optimizes heat dissipation for high-power transceivers.
  • MSA Compatibility: Fully mates with QSFP MSA compliant transceivers for seamless network integration.
  • Effective EMI Shielding: Stainless steel spring fingers reduce electromagnetic interference to ensure signal integrity.
  • RoHS Compliant: Manufactured following strict environmental standards under EU Directive 2011/65/EU.

Packing Details

If you need detailed information about our packaging specifications and requirements, please feel free to contact us directly. We will be happy to provide you with the details.

Applications

• 100G Enterprise Switches
• Core Network Routers
• Data Center Storage Systems
• Optical Transceiver Modules
• Network Interface Cards (NIC)



Frequently Asked Questions (FAQ)

Q: What are the benefits of using a QSFP28 1x1 cage with heatsink in data center switches?
A: A QSFP28 1x1 cage with heatsink significantly improves thermal dissipation for 100G transceivers, preventing thermal throttling and maintaining stable high-speed data transmission in dense server racks.

Q: Is the S501120010SA4 cage compatible with standard QSFP MSA transceivers?
A: Yes, S501120010SA4 is fully compliant with QSFP MSA specifications, ensuring seamless mechanical pluggability and electrical compatibility with standard optical modules.

Q: How to install QSFP28 1x1 cage on host PCB board correctly?
A: Place the cage compliant press-fit pins into the recommended PCB drill holes according to drawing specifications, ensuring chassis ground pads mate properly with the bezel opening.
