SFP+ 2x8 Cage with Integrated Connector High Density SFP Cage Connector S202H23004BA4（Cross out TE 1-2149490-5）

Product Overview

SFP+ 2x8 Cage with Integrated Connector S202H23004BA4 provides a 16-port stacked solution for high-density switches and routers. Featuring integrated light pipe and stainless steel spring components, it ensures strong electromagnetic suppression, robust mechanical retention, and optimal optical signal indication across industrial networking setups.

Product Specifications

Product Features

• • High-Density Porting: Stacked 2x8 configuration provides 16 ports in a compact layout.
  • Integrated Optical Pipe: Clear polycarbonate light pipes deliver immediate port activity visual feedback.
  • Durable Spring Design: Stainless steel spring elements guarantee solid physical retention and EMI protection.
  • Gold-Plated Contacts: Phosphor bronze contacts with 15u" gold plating ensure reliable signal performance.
  • Wide Thermal Tolerance: Operates dependably in harsh environments between -40°C and +85°C.

Packing Details

If you need detailed information about our packaging specifications and requirements, please feel free to contact us directly. We will be happy to provide you with the details.

Applications

• • High-Density Switches
  • Enterprise Core Routers
  • Data Center Servers
  • Telecommunication Hubs
  • Optical Transceiver Modules

Frequently Asked Questions (FAQ)

Q: What are the performance benefits of a stacked SFP+ 2x8 cage with integrated connector for high density switches?
A: A stacked SFP+ 2x8 cage with integrated connector optimizes board real estate by packing 16 ports into a compact footprint while offering lower insertion loss, excellent EMI grounding, and simplified board assembly for enterprise switches.

Q: How does the light pipe integration work in the S202H23004BA4 SFP+ assembly?
A: Clear polycarbonate light pipes route light directly from board-mounted LEDs to the front panel bezel, allowing real-time port link and activity status monitoring without requiring extra external panel indicators.

Q: Is the S202H23004BA4 suitable for extended temperature environments?
A: Yes, it operates within a wide temperature range of -40°C to +85°C and can be safely stored from -55°C to +105°C, making it suitable for demanding industrial telecom deployments.
