High Frequency Test RF Adapter SMA Female 18GHz SMA-KKG

This high-precision SMA female to female interface is a specialized High Frequency Test RF Adapter designed to provide a stable and low-loss connection for wideband microwave circuit testing and instrument calibration.

This SMA series RF coaxial adapter is designed as a precision female-to-female interconnection device serving as an essential High Frequency Test RF Adapter for laboratory, production, and field test environments. Featuring a compact barrel form factor with a robust stainless steel body, beryllium copper center contacts, and PTFE dielectric insulation, it delivers outstanding electrical repeatability and mechanical durability across the full DC to 18 GHz frequency range. The 50-ohm characteristic impedance and VSWR of 1.15 or less ensure minimal signal reflection, making it ideal for vector network analyzer calibration, spectrum analysis, and high-speed digital testing applications.

This High Frequency Test RF Adapter delivers precision performance for millimeter-wave test applications. With 50 Ohm impedance and DC to 40GHz frequency coverage, it supports 5G NR, satellite communications, and aerospace RF testing. The stainless steel body and gold plated beryllium copper inner conductor ensure excellent performance and long mating life.

The 2.92-JKG is a precision 2.92mm (K-connector) male-to-female high frequency test RF adapter designed for laboratory, automated test equipment (ATE), and microwave measurement applications up to 40GHz. Featuring a 50Ω characteristic impedance and VSWR ≤1.15, it provides outstanding signal integrity at millimeter-wave frequencies, making it an essential interconnect for vector network analyzer calibration and device characterization.

The 2.4/2.92-JKG is a cross-interface high frequency test RF adapter that bridges 2.4mm and 2.92mm (K-connector) interfaces in a single precision interconnect rated to 40GHz.With 50Ω impedance, VSWR ≤1.15, and 1000V dielectric withstanding voltage, this adapter simplifies multi-standard RF test setups by eliminating separate adapters for 2.4mm and 2.92mm ports on VNAs and ATE equipment.

The 1.85-JKG is a precision High Frequency Test RF Adapter featuring a female-to-female (jack-to-jack) inline configuration designed for millimeter-wave test and measurement applications up to 67 GHz. With 50 Ohm characteristic impedance and VSWR of 1.25 maximum across the full operating band, this adapter delivers exceptional signal integrity for vector network analysis, RF component characterization, and high-speed digital interconnect testing.Constructed with stainless steel body, beryllium copper center contacts, and PTFE dielectric, the 1.85-JKG ensures repeatable, low-loss connections in demanding laboratory and production test environments.

This high-performance SMA Female to eMFBX Male Test RF Adapter is engineered to provide a seamless and reliable interface for precision high-frequency measurement applications, ensuring superior signal integrity between different connector standards.

This high-performance SMA Female to eMBX Male Test RF Adapter is engineered to provide a seamless and reliable interface between different connector standards, ensuring superior signal integrity for precision high-frequency measurement applications.

This precision-engineered SMA Female to eSMP-MAX Female Test RF Adapter is specifically designed to provide a stable and high-performance interface for high-frequency measurement systems, ensuring optimal signal integrity between different connector standards.

This high-performance SMA Female to eZSMP Female Test RF Adapter is meticulously engineered to provide a seamless and reliable interface between connector standards, ensuring superior signal integrity for high-frequency measurement and communication systems.

This high-performance SMA Female to ePSMP Female Test RF Adapter is meticulously engineered to provide a seamless and reliable interface between different connector standards, ensuring superior signal integrity for high-frequency measurement applications.

This professional-grade 4.3/10 Male to SMA Female Test RF Adapter is meticulously engineered to provide a seamless and reliable interface between different connector standards, ensuring superior signal integrity for precision high-frequency measurement applications.
