RF Adapter&Cable Assembly Millimeter-Wave Test Cable AssemblyPrecision Quick-Connect N Male to N Male 6GHz VSWR Test Cable Assembly 142-NM-NM-L
VSWR Test Cable Assembly provides exceptional RF performance up to 6GHz for reliable test setups. Featuring a fast quick-connect design with moveable coupling nut, model 142-NM-NM-L ensures seamless N Male to N Male mating, low insertion loss (≤1.35dB/m), and superior VSWR (≤1.2). Built with stainless steel and beryllium copper, this high frequency 6GHz VSWR Test Cable Assembly is engineered for maximum durability, stable signal transmission, and rapid production line testing.
Part Number :
142-NM-NM-L(Quick-connect type: The coupling nut can move forward and backward)Product Category :
rf adapter & cable assembly
Product Overview
VSWR Test Cable Assembly (Model 142-NM-NM-L) is designed for high-precision RF test environments. Operating from DC to 6GHz with VSWR ≤ 1.2, it features a unique quick-connect mechanism with a forward/backward sliding coupling nut. This durable low loss VSWR Test Cable Assembly ensures fast, repeatable, and low-loss interconnects for laboratory and factory testing.
Product Specifications / Attributes
Specification data for this precision quick-connect VSWR Test Cable Assembly:
| Parameter | Specification Details |
| Model / Part Number | 142-NM-NM-L |
| Connector Interface | N Male to N Male (Quick-Connect Slide Type) |
| Characteristic Impedance |
50 Ω |
| Frequency Range |
DC ~ 6 GHz |
| VSWR |
≤ 1.2 |
| Insertion Loss |
≤ 1.35 dB/m |
| Dielectric Withstanding Voltage |
1000 V |
| Insulation Resistance |
5000 MΩ |
| Materials |
Stainless Steel, Beryllium Copper, PEI |
| Mechanism Feature |
Coupling nut moves forward and backward for quick connection |
Features&Benefits
Packing Details
If you need detailed information about our packaging specifications and requirements, please feel free to contact us directly. We will be happy to provide you with the details.
Applications
Frequently Asked Questions (FAQ)
Q: How does the quick-connect feature work on model 142-NM-NM-L?
A: The coupling nut moves forward and backward freely, allowing users to slide and lock onto standard N female test ports instantly without full rotational threading, significantly speeding up testing routines.
Q: What RF performance can I expect from this Precision quick-connect VSWR test cable assembly?
A: It offers robust performance across DC to 6GHz, maintaining a low VSWR ≤ 1.2, insertion loss ≤ 1.35dB/m, and high insulation resistance of 5000MΩ for accurate signal integrity.
Q: Where is this Durable low loss VSWR test cable assembly typically deployed?
A: It is ideal for high-volume RF production lines, laboratory VNA calibrations, antenna testing, and automated test equipment requiring fast, repeatable, and low-loss interconnects.
